The Jayco Melbourne Prestige Class C diesel motorhome has been carefully crafted with premium comforts in a shorter package! Jayco has taken the extra steps to build a high quality product that is durable with the most advanced construction techniques, as well as built by Amish craftsmen who have honed the woodworking skills.



The Stronghold VBL™ vacuum-bonded roof, floor, and sidewalls, the bead-foam insulation, the heated holding tanks, and the premium Sikkens full-body paint ensures you will have years of use in any season. The interiors have an exquisite design with the Tecnoform® high-gloss cabinetry and countertops, the high-intensity hardwood fascia, the custom-molded ABS surround in the cab-over area, and the decorative kitchen backsplash. You won't have to worry about getting lost either with the 10.25 inch integrated Mercedes-Benz® infotainment center with GPS.



Tour a Jayco Melbourn Prestige Class C diesel motorhome and discover all of the carefully selected upgrades throughout for a luxurious experience!

  • Melbourne Prestige 24LP

    Melbourne Prestige 24LP Floorplan Image

    Take a Virtual Tour

    Jayco Melbourne Prestige Class C diesel motorhome 24LP highlights: Ultraleather ... more about Melbourne Prestige 24LP

    Specifications

    Sleeps 6
    Slides 1
    Length 25 ft 2 in
    Ext Width 8 ft
    Ext Height 10 ft 11 in
    Int Height 6 ft 8 in
    Interior Color Hudson
    Exterior Color Dawn, Dusk, Twilight
    Hitch Weight 5000 lbs
    Gross Weight 11030 lbs
    Fresh Water Capacity 43 gals
    Grey Water Capacity 31 gals
    Black Water Capacity 31 gals
    Tire Size 215/85R16
    Furnace BTU 20000 btu
    Generator 3.6KW Onan LP
    Fuel Type Diesel
    Engine V-6 Turbo
    Chassis Mercedes Benz 3500
    Horsepower 188 hp
    Fuel Capacity 26.4 gals
    Wheelbase 170 in
    Number Of Bunks 1
    Available Beds Queen
    Torque 325 ft-lb
    Refrigerator Type Gas/Electric
    Refrigerator Size 6 cu ft
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 24" x 32"
    Number of Awnings 1
    LP Tank Capacity 12.2 gals
    Water Heater Capacity 6 gal
    Water Heater Type Truma AquaGo Comfort Plus
    AC BTU 15000 btu
    Basement Storage 14 cu. ft.
    TV Info LR LED
    Awning Info 14' Electric with LED Light Strip
    Gross Combined Weight 15250 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Melbourne Prestige 24RP

    Melbourne Prestige 24RP Floorplan Image

    Take a Virtual Tour

    Jayco Melbourne Prestige Class C diesel motorhome 24RP highlights: Overhead Bunk ... more about Melbourne Prestige 24RP

    Specifications

    Sleeps 5
    Slides 1
    Length 25 ft 2 in
    Ext Width 8 ft
    Ext Height 10 ft 11 in
    Int Height 6 ft 8 in
    Interior Color Hudson
    Exterior Color Dawn, Dusk, Twilight
    Hitch Weight 5000 lbs
    Gross Weight 11030 lbs
    Fresh Water Capacity 35 gals
    Grey Water Capacity 31 gals
    Black Water Capacity 31 gals
    Tire Size 215/85R16
    Furnace BTU 20000 btu
    Generator 3.6KW Onan LP
    Fuel Type Diesel
    Engine V-6 Turbo
    Chassis Mercedes Benz 3500
    Horsepower 188 hp
    Fuel Capacity 26.4 gals
    Wheelbase 170 in
    Number Of Bunks 1
    Available Beds Queen Murphy
    Torque 325 ft-lb
    Refrigerator Type Gas/Electric
    Refrigerator Size 6 cu ft
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 24" x 32"
    Number of Awnings 1
    LP Tank Capacity 12.2 gals
    Water Heater Capacity 6 gal
    Water Heater Type Truma AquaGo Comfort Plus
    AC BTU 15000 btu
    Basement Storage 17 cu. ft.
    TV Info LR LED
    Awning Info 14' Electric with LED Light Strip
    Gross Combined Weight 15250 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Melbourne Prestige 24TP

    Melbourne Prestige 24TP Floorplan Image

    Take a Virtual Tour

    Jayco Melbourne Prestige Class C diesel motorhome 24TP highlights: Rear Twin ... more about Melbourne Prestige 24TP

    Specifications

    Sleeps 5
    Slides 1
    Length 25 ft 2 in
    Ext Width 8 ft
    Ext Height 10 ft 11 in
    Int Height 6 ft 8 in
    Interior Color Hudson
    Exterior Color Dawn, Dusk, Twilight
    Hitch Weight 5000 lbs
    Gross Weight 11030 lbs
    Fresh Water Capacity 43 gals
    Grey Water Capacity 31 gals
    Black Water Capacity 31 gals
    Tire Size 215/85R16
    Furnace BTU 20000 btu
    Generator 3.6KW Onan LP
    Fuel Type Diesel
    Engine V-6 Turbo
    Chassis Mercedes Benz 3500
    Horsepower 188 hp
    Fuel Capacity 26.4 gals
    Wheelbase 170 in
    Number Of Bunks 1
    Available Beds Two Twins
    Torque 325 ft-lb
    Refrigerator Type Gas/Electric
    Refrigerator Size 6 cu ft
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 19" x 28" x 34"
    Number of Awnings 1
    LP Tank Capacity 12.2 gals
    Water Heater Capacity 6 gal
    Water Heater Type Truma AquaGo Comfort Plus
    AC BTU 15000 btu
    Basement Storage 40 cu. ft.
    TV Info LR LED
    Awning Info 14' Electric with LED Light Strip
    Gross Combined Weight 15250 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

  • Melbourne Prestige 24KP

    Melbourne Prestige 24KP Floorplan Image

    Jayco Melbourne Prestige Class C diesel motorhome 24KP highlights: Overhead Bunk ... more about Melbourne Prestige 24KP

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 2
    Length 25 ft 2 in
    Ext Width 8 ft
    Ext Height 10 ft 11 in
    Int Height 6 ft 8 in
    Interior Color Hudson
    Exterior Color Dawn, Dusk, Twilight
    Hitch Weight 5000 lbs
    Gross Weight 11030 lbs
    Fresh Water Capacity 43 gals
    Grey Water Capacity 31 gals
    Black Water Capacity 31 gals
    Tire Size 215/85R16
    Furnace BTU 20000 btu
    Generator 3.6KW Onan LP
    Fuel Type Diesel
    Engine V-6 Turbo
    Chassis Mercedes Benz 3500
    Horsepower 188 hp
    Fuel Capacity 26.4 gals
    Wheelbase 170 in
    Number Of Bunks 1
    Available Beds Queen
    Torque 325 ft-lb
    Refrigerator Type Gas/Electric
    Refrigerator Size 6 cu ft
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 24" x 32"
    Number of Awnings 1
    LP Tank Capacity 12.2 gals
    Water Heater Capacity 6 gal
    Water Heater Type Truma AquaGo Comfort Plus
    AC BTU 15000 btu
    Basement Storage 42 cu. ft.
    TV Info LR LED
    Awning Info 14' Electric with LED Light Strip
    Gross Combined Weight 15250 lbs
    Shower Type Standard
    Electrical Service 30 amp

    Similar Floorplans

Melbourne Prestige Features:

Standard Features (2021)



Customer Value Package

  • One-piece, seamless, fiberglass front cap
  • Automotive-bonded, panoramic window in front cap with power shade
  • Frameless windows
  • Backup camera
  • Girard® armless patio awning with LED light strip
  • Heated holding tanks (12V pads)
  • Truma AquaGo Comfort Plus tankless water heater
  • Remote keyless entry
  • Ultraleather® swivel driver and passenger seats with boosters

Driving Equipment

  • Mercedes-Benz® 3500 chassis with 170 in. wheelbase
  • GVWR- 11,030 lb.
  • GCWR- 15,250 lb.
  • V-6 Turbo 188 HP diesel engine with electronic fuel injection and 325 ft.-lb. torque
  • 7-speed automatic transmission
  • 220-amp alternator
  • E-rated highway tires- 215/85R16
  • Aluminum rims
  • Front and rear disc, 4-wheel anti-lock brakes
  • 5,000 lb. rear hitch receiver with dual connector
  • 7-pin plug
  • 12V chassis battery
  • 26.4 gal. fuel tank
  • 5.8 gal. DEF tank
  • 10.25 in. integrated Mercedes-Benz® infotainment center with GPS
  • Driver and passenger airbags
  • Power windows and door locks
  • Tilt steering wheel
  • A/C and cruise control
  • Auxiliary start switch
  • Cab area privacy curtain

Exterior Equipment

  • Stronghold VBL™ Vacuum-Bond laminated roof, floor and sidewalls
  • Bead-foam insulation (R-24 max roof, R-9 max floor, R-8 max walls)
  • One-piece, seamless, fiberglass roof
  • Partial fiberglass rear cap
  • Premium Sikkens full-body paint
  • Chrome grill package
  • Electric stabilizer jacks
  • Slideout cover awnings
  • Entrance door with industry’s largest travel-view window
  • Electric-powered entrance step with integrated house battery compartment
  • (2) 12V house batteries
  • Aluminum skirt-hung baggage doors
  • 12.2 gal. propane tank (41 lb.)
  • LP quick-connect hookup
  • Exterior utility center
  • Winterization drain system
  • Black tank flush
  • Outside shower
  • 12V demand water pump
  • Onan® 3,600-watt LP generator
  • 30-amp electrical service
  • 1,000-watt inverter
  • Solar prep
  • Flush-mount LED marker lights
  • Third brake light
  • Porch light

Interior Equipment

  • Custom-molded ABS surround in cab-over area
  • Overhead bunk with 750 lb. capacity
  • 80 in. interior ceiling height with padded vinyl ceiling
  • High-intensity LED ceiling lights
  • High-gloss hardwood fascia
  • Tecnoform® high-gloss cabinetry
  • Ball-bearing drawer guides
  • Jayco-exclusive, easy-operation legless dinette table (24KP)
  • U-shaped dinette with stow-away pedestal legs (24LP)
  • 12V USB charging station in dinette area
  • 2-point lap safety belts in all designated seating locations
  • Day/night roller shades
  • 15,000 BTU low-profile A/C
  • 20,000 BTU auto-ignition ducted furnace
  • Powered roof vent in living area with wall switch
  • LED living room TV
  • Blu-Ray™ player in living area
  • Prep for satellite dish
  • Cable TV hookup with RG-6 coax
  • Digital antenna with signal booster
  • 6 cu.ft. gas/electric/12V refrigerator
  • Suburban 2-burner, drop-in cooktop with flush cover
  • Under-mounted convection microwave
  • Tecnoform® high-gloss countertops
  • Stainless-steel sink with wooden cover/cutting board
  • Decorative kitchen backsplash
  • Water filtration system
  • Shower with decorative surround and skylight
  • Stainless-steel bathroom sink
  • Porcelain toilet with foot flush
  • Powered roof vent in bathroom with wall switch
  • Queen-sized bed with bedspread (24KP, 24LP)
  • Queen-sized power Murphy bed (24RP)
  • (2) Twin-sized beds (24TP)
  • Under-bed storage (select models)
  • Bedroom TV prep
  • Large wardrobes
  • Smoke alarm
  • Carbon monoxide detector

Exterior

  • Dawn Full Body Paint
  • Dusk Full Body Paint
  • Twilight Full Body Paint

Decor

  • Hudson

Options

  • Canadian Standards
  • CSA Chassis Upcharge
  • Customer Value Package
    • Backup camera, electric awning with LED lights, frameless windows, infotainment system, keyless cab entry, remote-controlled and heated mirrors, swivel driver and passenger seats, tank heating pads
  • Sun Folding Windshield Shade
  • Hydraulic Leveling Jacks
  • 3.2 KW Diesel Generator
  • B-Plus Front Cap
  • Theater Seating ILO Dinette (24KP, 24LP)

Please see us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
